Self-Adhesive Tape & Paper Coating Plant
Self-Adhesive Tape Industries & Paper Industries Coating Plant — BOPP, polyester, foam, PVC, paper, thermal & release paper. Up to 1000–1350 mm width, 30–90 ft chamber.
Factory-direct pricing, custom-built to your width, speed & material. Share your requirement for a quick quotation.
- Made in India
- Pan-India delivery in 4–6 weeks
- Lifetime spares support
- Machine StructureMS Plate Heavy Duty
- Maximum Roll Width1000 mm – 1350 mm (customisable)
- Coating Chamber30 ft to 90 ft length
- Heating SystemPellet / Diesel / Electrical
- RollersDrum, Knurling, Aluminium Guide, Banana Rubber
- Control PanelAC Digital Frequency Drive
About this machine
Yogi Engineering Works's Self-Adhesive Tape & Paper Industries Coating Plant & Machinery is built on an MS plate heavy-duty structure and processes polyester-BOPP film, foam and PVC (tape coating) as well as paper, paper cup, thermal, sublimation, release and wax paper (paper coating). Maximum roll width is 1000–1350 mm standard (customisable), with a coating chamber from 30 ft to 90 ft length and a choice of pellet, diesel or electrical heating. The line includes drum roller, knurling roller, aluminium guide roller and banana rubber roller assemblies, an AC motor with AC digital frequency drive control panel (start/stop, length counting meter, speed sensor, emergency stop), jumbo roll capacity up to 1000 kg, auto tension control and an optional single-colour printing attachment. High-speed 3-drive / 4-drive systems are available; rewinding speed 30 to 100 MPM.
Full specifications
| Machine Structure | MS Plate Heavy Duty |
|---|---|
| Maximum Roll Width | 1000 mm – 1350 mm (customisable) |
| Coating Chamber | 30 ft to 90 ft length |
| Heating System | Pellet / Diesel / Electrical |
| Rollers | Drum, Knurling, Aluminium Guide, Banana Rubber |
| Control Panel | AC Digital Frequency Drive |
| Jumbo Roll Capacity | Up to 1000 kg |
| Rewinding Speed | 30 to 100 MPM |
| Drive | 3 Drive / 4 Drive (high speed) |
| Power Supply | Three Phase 415 V / 50 Hz |
Key features
- Processes both tape-industry and paper-industry materials
- Pellet / diesel / electrical heating options
- Auto tension control system for jumbo unwinder
- Drum, knurling, aluminium guide & banana rubber rollers
- Optional single-colour printing attachment for BOPP tape coating
- 3-drive / 4-drive high-speed system
- Jumbo roll capacity up to 1000 kg
Also known as / related searches
The Self-Adhesive Tape & Paper Coating Plant is also searched for as:
- Self Adhesive Tape Coating Machine
- Adhesive Tape Coating Machine
- BOPP Tape Coating Plant
- BOPP Tape Coating Machine
- Tape Industries Coating Machine
- Paper Industries Coating Machine
- Thermal Paper Coating Machine
- Release Paper Coating Machine
- Wax Paper Coating Machine
- Paper Cup Coating Machine
- Coating Plant
- Tape Coating Machine
- Sublimation Paper Coating Machine
- Wax Coating Machine
- Self Adhesive Tape Industries And Paper Industries Coating Plant And Machinery
